MODEL DD90 F012060 F012090 F012120 F012150 F024060 F024090 F024120 F024150 F090060 Rated Voltage
V 12 24 90 Rated Output
W 60 90 120 150 60 90 120 150 60 Rated Current
A 7.0 10.6 14.1 17.6 3.5 5.3 7.0 8.8 0.9 Rated Speed
r/min 3000 Rated Torque
kgf-cm 1.9 2.9 3.9 4.9 1.9 2.9 3.9 4.9 1.9 Weight
kg 2.1 2.2 2.9 3.4 2.1 2.2 2.9 3.1 2.1
MODEL DD90 F090090 F090120 F090150 F090200 F180060 F180090 F180120 F180150 F180200 F180250 Rated Voltage
V 90 180 Rated Output
W 90 120 150 200 60 90 120 150 200 250 Rated Current
A 1.4 1.9 2.3 3.1 0.5 0.7 0.9 1.2 1.6 2.0 Rated Speed
r/min 3000 Rated Torque
kgf-cm 2.9 3.9 4.9 6.5 1.9 2.9 3.9 4.9 6.5 8.1 Weight
kg 2.1 2.2 2.9 3.0 3.1 2.1 2.2 2.9 3.0 3.4
L MODEL 141.5
F012060/ /F012090 / F024060 / F024090 / F090060 / F090090 / F180060 / F180090 159.5
F012120 / F024120 / F024150 / F090120 / F090150 / F180120 / F180150 / F180200 184.5
F012150 / F090200 / F180250
